TVLogic LUM-181H User Manual

05 MENU OPERATIONS
27
4K /UHD HDR Emulation LCD Monitor
[4] Marker
● Fit Marker
- Used to acvate or inacvate the FIT
MARKER funcon.
- When the Marker type is selected in
the Marker menu, a border line of the
Safety Area will be displayed inside the
Marker. Images below show the dierence
between Fit Marker [ON] and [OFF].
- FIT MARKER ON/OFF displays as shown below
● Marker Mat
- Used to set the darkness level outside of
the MARKER area from [OFF](transparent) to
[7](Black).
- The higher the level is, the darker the outside
of the MARKER area is.
● Marker Color
- Used to control the color of MARKER lines.
- Available colors are [White], [Gray], [Black],
[Red], [Green], [Blue], [Dynamic].
● Thickness
- The item controls the thickness of the
MARKER lines.
- The degrees of thickness are between [1] ~ [7].
● Marker
- Used to select the marker type when the
MARKER is displayed on the screen.
- MARKER may only be acvated by pressing
the MARKER buon on the boom front of
the monitor.
- Available marker types are [O], [16:9], [4:3],
[4:3] ON AIR, [15:9], [14:9], [13:9], [1.85:1],
[2.35:1], [1.85:1 & 4:3], [4:3 ALT 14:9], [16:9
ALT 14:9], [16:9 ALT 4:3] and [USER].
● Center Marker
- Used to select the availability of the CENTER
MARKER on the screen.
- This funcon operates only aer acvang
the MARKER funcon by pressing the
MARKER buon on the boom front of the
monitor.
● Safety Area
- Used to select and control the size and
availability of the SAFETY AREA.
- Available types are [80%], [85%], [88%],
[90%], [93%], [100%], [EBU ACTION 16:9],
[EBU GRAPHIC 16:9], [EBU Acon 14:9],
[EBU Graphic 14:9], [EBU Acon 4:3] and
[EBU GRAPHIC 4:3].
- This funcon operates only aer acvang
the MARKER funcon and by pressing the
MARKER buon on the boom front of the
monitor.
● MARKER : 4:3
● SAFETY AREA : 90%
● FIT MARKER : OFF
● MARKER : 4:3
● SAFETY AREA : 90%
● FIT MARKER : ON
