TVLogic LVM-071W User Manual

Multi Format LCD Monitor
26
Other Functions
[4] PIXEL TO PIXEL
LVM-071W /091W monitor’s Pixel to Pixel mode displays input signal without scaling.
Press [UNDERSCAN] button on the front of the monitor to activate the[Pixel To Pixel] mode.
In the [Pixel To Pixel] mode, use the [UP]/[DOWN] buttons to toggle between 1:1 scan sections.
# Pixel To Pixel mode is not available in Graphic mode.
# Pixel To Pixel mode is available in SD mode, but 1:1 sections cannot be rotated through
as with HD sources.
Pixel To Pixel CENTER
Input Action Button Available Modes
Input Action Button Available Modes
HD 1080i/1080p
HD 720p
[UP]
(Clockwise)
[DOWN]
(Opposite)
[UP]
(Clockwise)
[DOWN]
(Opposite)
Center -> Left Top ->Mid Top -> Right Top ->
Right Mid -> Right Bottom -> Mid Bottom -> Left
Bottom -> Left Mid -> Center -> ….
Center -> Left Mid -> Left Bottom -> Mid Bottom
-> Right Bottom -> Right Mid -> Right Top -> Mid
Top -> Left Top -> Center -> …
Center -> Left Top -> Right Top -> Right Bottom
-> left Bottom -> Center -> …
Center -> Left Bottom -> Right Bottom ->
Right Top -> Left Top -> Center -> ….
After two seconds
