TVLogic LVM-071W User Manual

LVM-071W
Product Specication
Multi Format LCD Monitor
35
Input
1 x DVI-I DVI IN / VGA IN
3 x BNC
Analog Input
1 x BNC
SDI 1 Channel Inp ut
Output
1 x BNC
SDI Channel (Active Through Out)
Input Signal
Analog
Composite / S-Video / Component / RGB
HD-SDI
1.485Gbps
SD-SDI
270Mbps
DVI/VGA
640×480 / 800×600 / 1024×768 / 1280×768 / 1280x1024
Analog Input Spec
Composite
1.0Vpp (With Sync)
S-Video
1.0Vpp (Y With S ync), 0.286Vpp(C)
Component
1.0Vpp (Y With S ync), 0.7Vpp (Pb,Pr)
RGB
1.0Vpp (G With Sync), 0.7Vpp (B,R)
SDI Input Signal Formats
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M
720p (60/59.94/50)
SMPTE-260M
1035i (60/59.94)
SMPTE-125M
480i (59.94)
ITU-R BT.656
576i (50)
Audi o In
Embedded Audio
Analog Stereo (Phone Jack)
Audi o Out
Analog stere o (Phone Jack)
Internal Speaker(Mono)
LCD
Size
7.0"
Resolution
800 x 480 (15:9)
Dot Pitch
0.190 mm
Col or
16.7M(true), 24bit
Viewing Angle (Typical)
H : 140degrees
V : 140degre es
Luminance of white
350 cd/㎡(Center)
Contrast
700:1
Display Area
152 x 91 mm
Power
12V DC
Power Consumption (Approx.)
18 Watts(DC)
Operating Temperature
-20 °C to 40 °C (-4 °F to 104 °F )
Storage Temperature
-30 °C to 50 °C (-22 °F to 122 °F )
Main Body Dimensions (mm/inch)
203 x 131 x 60 (8.39 x 5.16 x 2.36)
Main Body Dimensions (With S tand) 217 x 143 x 69 (8.54 x 5.63 x 2.72)
Weight
1Kg / 2.2 lb
Acces sory
DC Power Adapt er, Camera Mount
Opt ion 19” Rack Mount able Kit (3U) (Dual Monitor)
