TVLogic LVM-071W User Manual

Product Specication
Multi Format LCD Monitor
36
LVM-091W
Input
1 x DVI-I DVI IN / VGA IN
3 x BNC
Analog Input
2 x BNC
SDI 2 Channel Input
Output
1 x BNC
SDI Channel (Active Through Out)
Input Signal
Analog
Composite / S-Video / Component / RGB
HD-SDI
1.485Gbps
SD-SDI
270Mbps
DVI/VGA
640×480 / 800×600 / 1024×768 / 1280×768 / 1280x1024
Analog Input Spec
Composite
1.0Vpp (With Sync)
S-Video
1.0Vpp (Y With Sync), 0.286Vpp(C)
Component
1.0Vpp (Y With Sync), 0.7Vpp (Pb,Pr)
RGB
1.0Vpp (G With Sync), 0.7Vpp (B,R)
SDI Input Signal Formats
SMPTE-274M
1080i (60/59.94/50)
1080p (30/29.97/25/24/24sF/23.98/23.98sF)
SMPTE-296M
720p (60/59.94/50)
SMPTE-260M
1035i (60/59.94)
SMPTE-125M
480i (59.94)
ITU-R BT.656
576i (50)
Audi o In
Embedded Audio
Analog Stereo (Phone Jack)
Audi o Out
Analog stereo (Phone Jack)
Internal Speaker(Mono)
LCD
Size
9.0"
Resolution
800 x 480 (15:9)
Dot Pitch
0.246 x 0.246 mm
Col or
16.7M(true), 24bit
Viewing Angle (Typical)
H : 170 degrees
V : 170 degrees
Luminance of white
350 cd/㎡(Center)
Contrast
350:1
Display Area
196 x 118 mm
Power
12V DC/24V DC
Power Consumption (Approx.)
24 Watts(DC)/Max 2A
Operating Temperature
-20 °C to 40 °C (-4 °F to 104 °F )
Storage Temperature
-30 °C to 50 °C (-22 °F to 122 °F )
Main Body Dimensi ons (mm/inch) 223 x 175 x 83 (8.78 x 6.89 x 3.26)
Main Body Dimensi ons (Wit h Stand) 260 x 194 x 90 (10.23 x 7.63 x 3.54)
Weight
2.5Kg/5.51lb
Acces sory
DC Power Adapt er, Camera Mount
Opt ion 19” Rack Mount able Kit (3U) (Dual Monitor)
