TVLogic LVM-071W User Manual

Other Functions
Multi Format LCD Monitor
28
[5] USER ASPE
C
T
User Aspect create his own Aspect Ratio by
User Scan Mode
Activate User Aspect mode by pressing the
[Under Scan] button in front of the monitor
After activation, press [ENTER]button to get
ready for controlling
Adjust the ratio using [UP]/[DOWN] button.
Controlling range of width
- LVM-071W/091W : Min[100] ~ Max[800]
Controlling range of height
- LVM-071W/091W : Min[100] ~ Max[480]
The picture always stay in the middle of the display
# To adjust the 1920X1080 input whose resolution is 16:9 into 2.35:1 picture ratio, adjust the Width
and height 800X340 to make the picture ratio to 2.35:1.
