Multi Format LCD Monitor 11
LVM-171A : FRONT
LVM-171A : REAR
3. Controls & Functions
SCAN
ASPECT
MARKER
F1
F2
F3
MENU/
EXIT
UP/DOWN
/ENTER
USB
AUDIO OUT
POWER
SOURCE
CVBS
DVI-I
SDI-A IN
SDI-B IN
SDI OUT
HDMI
~AC IN DC 12V IN RS-422 IN
RS-422 OUT AUDIO IN LAN OUT
REMOTE LAN IN
