TVS electronics RP-3200 - Memory Switch Function Reference; Detailed Memory Switch Functions

Switch no. Function OFF ON
MSW1-1 Power ON Info Valid Not Send
MSW1-2 Buffer Size
4K bytes
45 bytes
MSW1-3 Busy Condition
Full/Err
Full
MSW1-4 Receive Error
Print“ ?”
No Print
MSW1-5 CR Mode
Ignored
LF
MSW1-6 Reserved
Fixed
—
MSW1-7 DSR Signal
Invalid
Valid
MSW1-8 Init Signal
Invalid
Valid
MSW2-1 Reserved — Fixed
MSW2-2 Auto Cutter Invalid
Valid
* MSW2-3 Spool Print
Invalid
Valid
MSW2-4 Full Col Print LineFeed
WaitData
MSW2-5 Resume aft PE
Next
Top
MSW2-6 Reserved
Fixed
—
MSW2-7 Reserved
Fixed
—
MSW2-8 PNE Sensor
Valid
Invalid
MSW3-1 Resume Cttr Err Valid Invalid
MSW3-2 PE signal by PNE Valid
Invalid
MSW3-3 Parallel 31 Pin
Valid
Invalid
MSW3-4 Reserved
Fixed
—
MSW3-5 Reserved
Fixed
—
MSW3-6 Reserved
Fixed
—
MSW3-7 CBM1000 Mode
Invalid
Valid
MSW3-8 Resume Open Err
Close
Command
MSW4-1 Reserved Fixed —
MSW4-2 Reserved Fixed —
MSW4-3 Feed&Cut at TOF Invalid Valid
MSW4-4 Reserved Fixed —
MSW4-5 Reserved Fixed —
MSW4-6 Reserved Fixed —
MSW4-7 Reserved Fixed —
MSW4-8 Partial Only Invalid Valid
MSW5-1 Buzzer Valid Invalid
MSW5-2 Line Pitch 1/360 1/406
MSW5-3 USB Mode Virtual COM Printer Class
MSW5-4 Reserved Fixed —
MSW5-5 Reserved Fixed —
MSW5-6 Reserved Fixed —
MSW5-7 Reserved Fixed —
MSW5-8 Reserved Fixed —
Sih
Fi
Iiil i
Si l
The function of each memory switch is shown in the following table. (Shaded
values are factory settings.)
— 40 —
