TVS HLX PLUS 2019 - Location of Parts (Left and Right Sides)

KNOW YOUR TVS HLX PLUS
KNOW YOUR TVS HLX PLUS
10
6. Speedometer cable
7. Front brake cable
8. Lock cover frame L
9. Handle pillion
1. Spark plug
2. Gauge oil level
3. Rear brake pedal
4. Kick starter lever
5. Cover frame R screw
6. Rear shock absorber R
7. Pillion foot rest R
8. Muffler assembly
9. Fuel tank cap
VEHICLE LEFT SIDE VEHICLE RIGHT SIDE
7
6
5 4
8
3 2 1
9
8
7
6
5 4
3 2 1
LOCATION OF PARTS
1. Pillion foot rest L
2. Rear shock absorber L
3. Chain inspection window
4. Gear shift lever
5. Fuel cock
9
