KNOW YOUR TVS HLX PLUS
KNOW YOUR TVS HLX PLUS
14
3. Turn signal lamp switch for ES & KS
When the turn signal lamp switch knob is pushed to the left
side ( ) or right side ( ), the turn signal lamps flashes
along with the indicator.
4. Clutch lever for ES & KS
Use clutch lever to disengage the drive to the rear wheel
while shifting the gears. Pressing the lever disengages the
drive.
5. Pass by switch for ES & KS
The head lamp high beam glows when the pass by switch
knob ( PASS ) is pressed.
Press the knob intermittently while overtaking another
vehicle during day time to give signal to the opposite
vehicles.
6. Head lamp high/low beam switch for ES & KS
Press the knob towards ‘ ’ to operate the head lamp high
beam.
Press the knob towards ‘ ’ to operate the head lamp low
beam.
4
1
5
7
23
6
Note
ES - Electric Starter.
KS - Kick Starter.
Handle bar left side for ES model
Handle bar left side for KS model
