Solo Pillion
Front 1.75 kg/cm² (25 PSI) 1.75 kg/cm² (25 PSI)
Rear 2.00 kg/cm² (28 PSI) 2.25 kg/cm² (32 PSI)
TYRES
Tyre pressure:
Check tyre pressure atleast once in a week if not more
frequently. Insufficient air pressure in the tyres not only
hasten tyre wear, but also seriously affects the stability of
the vehicle.
Under inflated tyres make smooth cornering difficult and
over inflated tyres decrease the tyre contact with the
ground which can lead to skidding and loss of control. Be
sure that the tyre pressure is within the specified limits at all
times.
FRONT WHEEL REMOVAL
1. Remove axle nut (1) along with a washer from front
wheel axle.
2. Pull out the axle (2) along with a washer from wheel
assembly.
3. Remove a spacer from right side of the wheel.
4. Place a support (wooden block) below the frame to
revent the vehicle from falling.
4. Lift the front fork assembly up, dislocate the brake
panel along with cables and slide the wheel out.
5. Reverse the procedure for reassembling. Locate the
lug on fork leg L to the slot in the brake panel while
reassembling.
MAINTENANCE
MAINTENANCE
38
