TVS HLX PLUS 2019 - Vehicle Front Side Components; Vehicle Rear Side Components

11
KNOW YOUR TVS HLX PLUS
KNOW YOUR TVS HLX PLUS
VEHICLE REAR SIDE
1. Mirror R
2. Tail / brake lamp assembly
3. Rear turn signal lamp R
4. Rear number plate
5. Pillion foot rest L
6. Rear turn signal lamp L
7. Mirror L
2
1
3
4
5
2
7
1
5
6
3
4
LOCATION OF PARTS
VEHICLE FRONT SIDE
1. Front turn signal lamp L
2. Head lamp assembly
3. Front number plate
4. Rider foot rest
5. Front turn signal lamp R
