TVS HLX PLUS 2019 - Headlamp Switch (KS Model); Electric Starter Switch (ES Model); Headlamp Switch (ES Model)

15
KNOW YOUR TVS HLX PLUS
KNOW YOUR TVS HLX PLUS
7. Head lamp switch for KS
Head lamp switch has two positions ‘ ’ and ‘ ’ to
control head lamp.
Off : Head lamp, speedometer lamps and tail lamp
are ‘OFF’ when the knob is positioned at ‘ ’.
On: Head lamp, speedometer lamps and tail lamp
glows when the knob is positioned at ‘ ’ and
engine is running.
Always use choke for cold starting.
Never open the throttle when the choke is applied, it may
lead to flooding of engine and difficulty in starting.
Always use the appropriate turn signal lamp when you
intend to change lanes or take turns. Be sure to switch
‘OFF’ the lamp after negotiating the lanes or turns.
Use appropriate head lamp high/low beam as per the traffic
and road conditions for your safety and to avoid
inconvenience to the opposite riders.
Caution
Warning
HANDLE BAR RIGHT SIDE FOR ES & KS MODELS
1.Electric Starter Switch for ES
Press the switch to start the engine electrically even when
the vehicle is in any gear.
2. Head lamp switch for ES
Head lamp switch has two positions ‘ ’ and ‘ ’ to
control head lamp.
Off : Head lamp, speedometer lamps and tail lamp
are ‘OFF’ when the knob is positioned at
‘ ’.
On: Head lamp, speedometer lamps and tail lamp
glows when the knob is positioned at ‘ ’
and engine is running.
3
1
2
Handle bar right side for ES model
4
