TVS iQUBE - Vehicle Top Side Controls

VEHICLE TOP SIDE
13
1. Instrument cluster
2. Hazard switch
3. Rear view mirror R
4. Right hand brake lever
5. Throttle grip
6. Park assist switch
7. Mode Switch
8. Ignition cum steering lock
9. Bag hook (front)
10. Charging Socket
11. Horn switch
12. Turn signal lamp switch
13. Left hand brake lever
14. Left hand brake lock lever
15. High/low beam switch
16. Rear view mirror L
