20
LOCATION OF PARTS - VEHICLE LEFT SIDE
1. Rear brake adjusting nut
2. Effortless easy center stand
3. Side stand
4. Pillion foot rest L
5. Speedometer Cable
6. Front brake adjusting nuts
7. Pillion handle
6
1
7
234
5
