LOCATION OF PARTS - VEHICLE FRONT & REAR
FRONT
1. LED Head lamp
2. Head lamp focus adjuster
3. Turn signal lamp front LH
4. Turn signal lamp front RH
5. Throttle cable adjuster
REAR
1. Turn signal lamp rear RH
2. Tail / brake lamp
3. Transmission oil level screw
4. Reflex reflector
5. Turn signal lamp rear LH
* License plates are mandatory accessory will be charged extra
3
5
1
2
4
1
5
4
2
3
