If the vehicle is driven with less engine oil and
transmission oil, the engine components will be severely
damaged.
Check the oil level between the services to avoid costly
damage. Do not fill excess oil it may cause oil leak.
Always use TVS TRU4 SKUUTA oil (SAE 10W30 API-SL,
JASO MB) only.
Caution
6. Wipe out the oil traces with a clean cloth to
prevent dust accumulation.
7. Assemble back the gauge oil level.
TRANSMISSION OIL - LEVEL
Check the transmission oil level periodically. To check
the transmission oil level follow the procedure given
below:
1. Place the vehicle on centre stand on a flat surface.
2. Wipe-off the surroundings of oil level screw.
3. Remove the transmission oil level screw along
with a gasket from the rear end of crankcase L.
4. Check for the flow of oil from oil level hole. If the
level is less (if there is no oil flow), top-up with
TVS TRU4 SKUUTA oil (SAE 10W30 API-SL, JASO
MB) till the oil just starts to flow out from the oil
level hole.
5. Wipe out the oil traces with a clean cloth to
prevent dust accumulation.
6. Inspect the condition washer while reassembling
the oil level screw. Replace if required.
