LED HEAD LAMP
TVS Jupiter 125 comes with a LED head lamp which
glows automatically once the engine is started. The
head lamp beam (high / low) can be controlled by by
changing the beam control switch position to ‘Low’
or ‘High’ beam.
HANDLE BAR LEFT SIDE
1. Horn switch
Press the switch ‘ ’ to operate the horn.
2. Turn signal lamp switch
Slide the turn signal lamp switch to the left ‘ ’
or right side ‘ ’ to operate respective turn signal
lamps (LH / RH). Press the switch to turn ‘OFF’.
Always use the appropriate turn signal lamps when you
intend to change lanes or take turns. Be sure to switch
‘OFF’ it after negotiating the lanes or turns.
1
2
3
5
4
