TVS JUPITER 125 - Electrical System Details

76
DESCRIPTION TVS Jupiter 125 (Sheet Metal Wheel - Drum Type)
ELECTRICAL
Speedometer lamp bulb 12V, 1.7W x 2
Turn signal indicator lamp bulb 12V, 1.7W x 2
High beam indicator lamp 12V, LED
Low fuel warning lamp 12V, LED
Economy and power mode indicator lamp 12V, LED
Malfunction indicator lamp 12V, LED
ISG malfunction indicator lamp 12V, LED
Horn 12V, DC
Fuse Blade type - 12V, 15A x 1 / Mini fuse 12V, 15A x 1 & 12V, 10A x 1
Using the bulb other than the specified rating can result in overloading of the electrical system or premature failure of the
bulb.
Caution
