TVS LP 46 PLUS - 1.5 Ribbon Specifications; 1.6 Media Specifications

5
1.5 Ribbon Specifications
Ribbon Specifications
Ribbon outside diameter
1” core: Max. 67mm
0.5” core: Max. 40mm
Ribbon length
1” inner core: 300 meters
0.5” inner core: 110 meters
Ribbon core inside diameter
0.5 and 1 inch
Ribbon width
40 ~ 110 mm
Ribbon wound type
Outside wound
1.6 Media Specifications
Media Specifications
LP 46 Plus
Label roll capacity
Max. 5”
OD
Media type
Continuous, die-cut, black mark, fan-fold,
notch
Media wound type
Outside
wound
Media width
20mm
~ Max.
112
mm
Media thickness
0.06 mm (2.36 mil) ~ 0.19 mm (7.48 mil)
Media core diameter
1” (25.4 mm) & 1.5” (38 mm) ID core
Label length
5 mm ~ Max. printing length
Label length (peeler mode)
1" ~ 6" (25.4 ~ 152.4 mm)
Label length (cutter mode)
1" ~ Max. printing length
Gap height
Min. 2
mm
(0.09”)
Black mark height
Min. 2
mm
(0.09”)
Black mark width
Min. 8
mm
(0.31”)
