1.1.2 Interior View
4
5
13
12
1. Printer top cover 8. Media supply spindle
2. Ribbon supply spindle 9. Platen roller
3. Ribbon supply hub 10. Black mark sensor
4. Ribbon rewind hub 11. Gap sensor
5. Ribbon rewind spindle 12. Media guide
6. Print head release button 13. Media guide adjustment knob
7. Fixing tabs 14. Print head
