22
Peel-off cover slot
5. Open the peel-off cover. Feed the
liner into peel-off cover slot.
6. Close the peel-off module. Use the
“Diagnostic Tool” to set the peel-off
mode by selecting “PEEL” option
for Post-Print Action setting then
click “Set” button to enable the
peel-off mode.
7. Close the media cover and complete
peeler module installation.
Note:
The peeler module only support plain paper.
