MAINTENANCE
36
MAINTENANCE
REAR SHOCK ABSORBERS
TVS Stryker 125 is provided with adjustable, series spring
rear shock absorbers to meet different road and load. There
are 5 notches for adjusting spring load conditions. If the
spring is adjusted to the minimum notch, then the shock
absorber will be softer which is good for light loads. If the
spring is adjusted to maximum notch, then it will be stiffer
which is good for heavy loads.
1
2
3
Adjust the spring pre-load by shifting the adjuster to the
required notch according to the different load conditions.
The more you compress the spring, the suspension
becomes more stiff.
SOFT
HARD
CAUTION
Keep both left and right shock absorbers spring adjusters in the
same position. Contact nearest TVS Motor Company Authorised
Distributor or Dealer / Authorised Service Centers for adjusting the
shock absorbers.
Too much or too less clutch lever free play will damage the clutch
plates, thereby affecting the performance of the vehicle.
Adjust clutch lever free play only when the engine is cold.
CAUTION
