MAINTENANCE
MAINTENANCE
37
2. Brake fluid level always should be above the ‘LOWER’
mark (B) provided on the master cylinder when the
master cylinder is parallel to the ground.
BRAKES
Front brake
You can observe a master cylinder (1) on the right side of the
handle bar, a caliper assembly (2) fitted to the fork leg R, a
disc (3) to the front wheel and a high pressure hose (4)
connecting the master cylinder and the caliper assembly.
1. Check the master cylinder brake fluid level through the
view piece glass (A).
3. If the brake fluid level is below the mark or while applying
brake if you feel the brake is more spongy or ineffective
due to air entry, contact TVS Motor Company Authorised
Distributor or Dealer / Authorised Service Centers for
topping-up the brake fluid, air bleeding and other brake
related inspections.
Brake pad wear indicator
Visually check the brake pads for wear. If the wear is found
beyond the wear indicator groove as shown in the figure
then replace the brake pads as a set with new one.
4
2
3
1
A
B
