TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
47
CHASSIS
Overall length : 2013 mm
Overall width : 752 mm
Overall height : 1085 mm
Ground clearance : 173 mm
Wheel base : 1273 mm
Kerb weight (with toolkit
and 90% of fuel) : 117 kg
Pay load : 130 kg
Maximum laden weight : 247 kg
Steering angle : 88°
Caster angle : 25°
Frame : Single cradle tubular frame
Front suspension : Telescopic oil damped
Rear suspension : Series spring Suspension
Trail length : 65 mm
TYRE
Tyre size
Front
Disc : 2.75 x 17
Rear
Drum : 90/90 - 17
Tyre pressure
2
Front : 1.75 kg/cm (25 PSI)
2
Rear - solo : 2.25 kg/cm (32 PSI)
2
Rear - dual : 2.53 kg/cm (36 PSI)
BRAKES
Front : Hand operated, 240 mm dia.
disc*
Rear : Foot operated, internally
expanding 130 mm dia. drum
ELECTRICAL
Type : Fly wheel magneto, AC
Ignition system : DC - Digital TCI
Spark plug : BOSCH UR4KC
Spark plug gap : 0.6 ~ 0.8 mm
