Warning
• You should adhere to the electric tester usage guidelines before checking the
power supply.
• Input AC voltage should be within the range of 220 to 240V.
• Need to ensure proper earth connection in the AC domestic power socket.
• Plug the charger in Single phase AC domestic socket only.
• Do not use extension box to charge the vehicle for safety purpose.
• The charger should be stored in a clean, dry and ventilated place.
• The charger fan should be in upward direction while charging.
• Never spray water or any liquid directly on the charger.
• Plug the charger in Single phase AC domestic socket only.
• Proper installation of power socket /board along with separate MCB and fuse
should be ensured.
• Cables utilized for socket connection, should be free of tapping and cuts.
• Power socket cables should be properly routed without any hanging cables and
must be enclosed in a conduit.
• Vehicle and charger positioning should be in such a way that, during charging the
cables are not overly stretched and connectors are properly locked in sockets.
• The charging location should be separate and away from other vehicles or
combustible materials and in well-ventilated areas.
Note
Unattended charging of the vehicles should be avoided. Charger should be placed away
from the vehicle above the ground level while charging. The charger fan and side vents
should not be obstructed, and fan should be upward facing while charging.
Note
Multimeter selector should be as shown in the picture for measuring AC voltage of
domestic power socket.
The selector position will vary in each multimeter brand.
Red & Black couplers need to be connected as shown in the picture with Multimeter
as well as the domestic 5A power socket.
