TVS X User Manual - Rev 0 - As on 16 July 2024
42
CHARGING THE VEHICLE
• The Phase, Neutral & Earth terminals should be placed as per the image.
• Use the Tester to find out the Phase line.
Caution
Any electrical work should be performed by authorized electrician only. Failure to do so
might result in severe injury or risk to life.
• As shown in this picture, you can check the input voltage of the available socket.
• Normally the reading would be 230 ± 5V.
Ac Socket
ON
ON
N P
E
To Next Page
