CHARGING
• Open the cap (A) of the charger’s charging cable.
• Carefully fix the charger cable into the charging port of the vehicle as shown and
ensure the proper locking of the cable with the vehicle.
• Plug the charger’s cable plug to AC socket only.
• RCD power indicator glows once the switch of the AC socket is turned ‘ON’.
• After completing the charging process, turn ‘OFF’ AC socket switch and pull out
the plug. Remove the charger’s cable from the vehicle by pressing the button (C).
Care should be taken not to damage the lock (B) while removing the cable from
the vehicle.
• Finally close the cap (A) of the charging cable and keep the charger in a safe and
secure place.
Note
If RCD LED indication is not observed while power is available in the domestic AC
socket, please press ‘Reset’ button and the LED would glow.
A
B
C
