On chip Xeon Thermal Sensor for 400Mhz FSB Xeon
Hardware Monitor Chip 4: Intel Xeon Thermal Sensor
Slave Address: 0x19h
Sensor Name Bank Register
CPU2 temperature 0 0x01h
Programming CPU thermal sensors for custom Hardware Monitoring
requirements (the GPIO pins are on ICH3)
GPIO27 GPIO28 CHANNEL# DEVICES
X X X Winbond 83782D (Always on)
1 1 3 DIMM SPD (6 devices), and CK408B clock chip
0 1 2 CPU1 and CPU2 Thermal sensor, Super IO
W83627HF
1 0 1 Reserved
0 0 0 Reserved
Note: if you experience problems with setting up your system, always check the following things in
the following order:
Memory, Video, CPU
By checking these items, you will most likely find out what the problem might have been when
setting up your system. For more information on troubleshooting, check the Tyan website at:
http://www.tyan.com.
