TYAN S5376 - Page 13

13
Jumper/Connector Function
P1 Rear Audio Header
J1 Front Panel Audio Header
J2 SO-DIMM Socket
LCM (J5) LCM Header
COM2 (J22) COM2 Connector
USB2 (J15) / USB3 (J16) USB Front Header
TYFP1 (J21) Front Panel Header
TYFP2 (J13) Front Panel Header 2 for Barebone
FAN CONN (J12) Fan Board Header for Barebone
SATA0~SATA5 Serial ATA Connector
PW1 24-pin Power Connector (EPS12V)
PW3 8-pin Power Connector (EPS12V)
PW2
Aux. Power Connector for TYAN Riser Card
(M2061)
CPUFAN1/CPUFAN2/
FAN1/FAN2/FAN3
4-pin Fan Header with Tachometer
JP1
SAS 1068E Device ID Change Jumper
Pin 1-2 closed: Device ID 58
Pin 2-3 closed: Device ID 59
JP2
VGA Enable/Disable Jumper
Pin 1-2 closed: Enable (default)
Pin 2-3 closed: Disable
JP3
Clear CMOS Jumper
Pin 1-2 closed: Normal (default)
Pin 2-3 closed: Clear
JP5
SAS 1068E Enable/Disable Jumper
Pin 1-2 closed: Enable (default)
Pin 2-3 closed: Disable
