Chapter 1: Introduction
1.1 - Congratulations
You have purchased one of the most powerful server solutions. The Tempest
i5100W (S5376) is a flexible Intel
®
platform for multiple applications, based on Intel
®
San Clemente MCH and ICH9R chipsets.
Designed to support two Intel
®
5100/5200/5400 Series processors and 48GB
DDR2-533/667 DIMM memory, and featured with integrated Dual 82573V LAN
controllers, built-in 32MB XGI Z9S video plus six SATA2 ports, the S5376 offers
exceptional performance and versatile solution for your server / Workstation.
Remember to visit TYAN’s Website at http://www.TYAN.com
. There you can find
information on all of TYAN’s products with FAQs, online manuals and BIOS
upgrades.
1.2 - Hardware Specifications
Processors
•Dual LGA771 sockets
•Supports up to two (2) Intel
®
5100/5200/5400 Series
processors
•1.33 / 1.06 GHz FSB
•VRD 11.0
Chipset
•Intel
®
San Clemente MCH
•ICH9R South Bridge
•Winbond 83627DHG Super I/O
chip
Expansion Slots
•One (1) PCI-E x16 slot w/ x16
signal from San Clemente
•Two (2) PCI-E x8 slots w/ x4
signal from San Clemente
•Three (3) 32/33 PCI 2.2 slots
•Total six (6) expansion slots
Back Panel I/O Ports
•Stacked PS/2 Mouse & Keyboard
ports
•Stacked two (2) USB 2.0 ports
•One (1) 9-pin COM port
•One (1) 15-pin VGA port
•Two (2) RJ45 10/100/1000 ports
with activity LED
•One (1) RJ45 10/100 port for SMDC
Integrated SATA Controller
(ICH9R)
•Supports six (6) SATA2 ports
running at 3.0Gb/s
•RAID 0/1/5/10 capable (Windows
OS only)
Integrated Video Controller
•XGI Z9S
•32MB DDR2 frame buffer memory
Integrated LAN Controllers
•Two 82573 (via PCI-E x1 signal)
