Jumpers & Connectors
Jumper/Connector Function
J26 IPMB Connector
J43/J44/J45/J46/J47/J48 Serial ATA Connector
J49/J50 Mini SAS Connector
J52/J54/J55/J56/J57/J58/J59 8-pin 4056 Fan Connector
J63 SAS Fault LED Connector
J64 PSMI Connector
J65 Front Panel Connector
J66 Power Button
J67 Reset Button
J71 2x10-pin Fan Connector for TYAN
J72 CMOS Clear Jumper
J75 SAS2008 Enable/Disable Jumper
J83 Chassis Intrusion Header
J90 SP5100 SATA SGPIO Pin Header
J91 ID LED Header (for TYAN FT48 chassis)
J92 SAS SMB & HDD Fault Header
J93 ID LED Button Header
J94/J95/J96/J97/J98 8-pin Fan Connector
LED25 BMC HB LED
LED26 SAS HB LED
LED28 Standby Power Ready LED
LED29 ID LED
USB1/USB2 USB FP Connector
USB3 Type-A Vertical USB Connector
Jumper Legend
OPEN - Jumper OFF
Without jumper cover
CLOSED - Jumper ON
With jumper cover
