3.7.1.2 ECC Configuration
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
ECC Configuration
ECC Mode
DRAM ECC Enable
DRAM SCRUB REDIRECT
DRAM BG Scrub
Data Cache BG Scrub
L2 Cache BG Scrub
L3 Cache BG Scrub
[Good]
[Enabled]
[Enabled]
[1.31ms]
[Disabled]
[Disabled]
[Disabled]
Set the level of ECC
protection. Note: The
“super” ECC mode
dynamically sets the
DRAM scrub rate so all of
memory is scrubbed in 8
hours.
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
ECC Mode
Select the level of ECC protection. Note: The “Super” ECC mode dynamically sets
the DRAM scrub rate so all of memory is scrubbed in 8 hours.
Basic / Super / Disabled / Good / Max / User
DRAM ECC Enable
DRAM ECC allows hardware to report and correct memory errors automatically
maintaining system integrity.
Enabled / Disabled
DRAM SCRUB REDIRECT
DRAM SCRUB REDIRECT allows the system to correct DRAM ECC errors
immediately when they occur, even if background scrubbing is on.
Enabled / Disabled
DRAM BG Scrub
DRAM scrubbing corrects memory errors so later reads are correct. Doing this while
memory is not being used improves performance.
Note: When AMD’s node interleave feature is enabled, BIOS will force DRAM scrub
off.
Disabled / 40ns / 80ns / 160ns / 320ns / 640ns / 1.28us / 2.56us / 5.12us /
10.2us / 20.5us / 41.0us / 81.9us / 163.8us / 327.7us / 655.4us / 1.31ms /
2.62ms / 5.24ms / 10.49ms / 20.97ms / 42.00ms / 84.00ms
Data Cache BG Scrub
Allow the L1 Data Cache RAM to be corrected while idle.
