Chapter 1: Instruction
1.1 Congratulations
You have purchased the powerful TYAN
®
S8010 motherboard, based on the
AMD
®
SR5670/5650 and SP5100 chipsets. The S8010 is designed to support
single AMD
®
45nm 4-Core/6-Core Opteron 4100 Series Processor and up to
64GB of DDR3 667MHz RDIMM and 16GB DDR3 1066MHz UDIMM. Leveraging
advanced technology from AMD
®
, the S8010 is capable of offering scalable 32
and 64-bit computing, high-bandwidth memory design, and lightning-fast PCI-E
bus implementation.
The S8010 not only empowers you in today’s demanding IT environment but also
offers a smooth path for future application upgradeability. All of these rich feature
sets provides the S8010 with the power and flexibility to meet demanding
requirements for today’s IT environments.
Remember to visit the TYAN
®
website at http://www.tyan.com. There you can
find all the information on all TYAN
®
products as well as all the supporting
documentation, FAQs, Drivers and BIOS upgrades.
1.2 Hardware Specifications
TYAN S8010 (S8010WGM2NR)
Supported CPU
Series
AMD 45nm 4-Core/6-Core Opteron 4100 Series
Processors (Lisbon)
Socket Type / Q'ty C32 / (1)
Average CPU Power
(ACP) wattage
Up to 75W
Processor
System Bus Up to 5.2 GT/s Hyper-Transport link support
Chipset AMD SR5670 + SP5100
Chipset
Super I/O Winbond W83627
Supported DIMM Qty (6) DIMM slots
DIMM Type / Speed U/RDDR3 & LV RDDR3, 800/1066/1333 MHz
Capacity
Up to 64GB DDR3 667 RDIMM/ 16GB DDR3 1066
UDIMM
Memory channel 2 Channels per CPU
Memory
Memory voltage 1.5V or 1.35V
PCI-E
(2) PCI-E Gen.2 x8 slots / (1) PCI-E Gen.2 x16 slot
(w/ x8 link)
Expansion
Slots
PCI (1) PCI 32-bit slot
Port Q'ty Total (3) ports, (1) dedicated for IPMI
Controller Intel 82574L
LAN
PHY Broadcom BCM5221 PHY (dedicated for IPMI
