TYAN S8010 - Page 70

http://www.tyan.com
70
3.7.1.1 Memory Configuration
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
Memory Configuration
Bank Interleaving
Node Interleaving
Channel Interleaving
CS Sparing Enable
Bank Swizzle Mode
[Auto]
[Disabled]
[Auto]
[Disabled]
[Enabled]
Enable Bank Memory
Interleaving
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Bank Interleaving
Bank Interleave setting has to do with the actual RAM chip properties, most good
quality RAM chips have "4-bank interleaving" and work best at this setting. Inter-
leaving controls how actual hits to memory takes place.
Enable Bank Memory Interleaving.
Auto / Disabled
Node Interleaving
Enable Node Memory Interleaving.
Disabled / Enabled
Channel Interleaving
Enable Channel Memory Interleaving.
Auto / Disabled
CS Sparing Enable
Reserve a spare memory rank in each node.
Disabled / Enabled
Bank Swizzle Mode
Enable or disable bank swizzle mode.
Enabled / Disabled
