TYAN S8010 - Page 59

http://www.tyan.com
59
3.3.8 Onboard Devices Configuration
Onboard Lan1/Lan2 (82574)
Enable /disable Lan controller.
Enabled / Disabled
Onboard Lan1/Lan2 OPROM
Execute Lan OP-ROM or not.
Disabled / Enabled
Onboard SAS
Enable /disable SAS controller.
Enabled / Disabled
Onboard VGA
Enable or disable the onboard VGA controller.
Enabled / Disabled
Serial Port1
Enable or disable the serial port 1.
Enabled / Disabled
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
Onboard Device and PCI Slots Configuration
Onboard LAN 1 (82574)
Onboard LAN 1 OPROM
Onboard LAN 1 (82574)
Onboard LAN 2 OPROM
Onboard SAS
Onboard VGA
Serial Port1
[Enabled]
[Disabled]
[Enabled]
[Disabled]
[Enabled]
[Enabled]
[Enabled]
Enabled
Disabled
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
