3.7.3.1.2 Port # 09/10 Features
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
Link ASPM
L1 Immediate ACK
[Disabled]
[Disabled]
Active State Power
Management
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Link ASPM
Active State Power Management.
Disabled / L0s / L1 / L0s & L1 / L0s Downstream / L0s Downstream + L1
L1 Immediate ACK
When Enabled L1 will be ACK’d immediately.
Disabled / Enabled
3.7.3.1.3 NB-SB Port Features
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
NB-SB Link ASPM [L1]
Disabled:
L1
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
NB-SB Link ASPM
Active State Power Management.
L1 / Disabled
