3.3.2 Advanced IDE Configuration
Onboard PCI IDE Controller
Disabled: disables the integrated IDE Controller
Primary: enables only the Primary IDE Controller
Secondary: enables only the Secondary IDE Controller
Both: enables both IDE Controller
Disabled / Primary / Secondary / Both
Hard Disk Write Protect
Disable/Enable device write protection. This will be effective only if device is
accessed through BIOS.
Disabled / Enabled
IDE Detect Time Out (Sec)
Select the time out value for detecting ATA/ATAPI device(s).
0~35 (at 5 interval)
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
IDE Configuration
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
OnBoard PCI IDE Controller
SATA0 (3M)
SATA1 (4M)
SATA2 (3S)
SATA3 (4S)
Hard Disk Write Protect
IDE Detect Time Out (Sec)
[Both]
[Not Detected]
[Not Detected]
[Not Detected]
[Not Detected]
[Disabled]
[35]
