TYAN S8238 - Page 47

http://www.tyan.com
47
3.3.3 ACPI Configuration
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
ACPI Settings
Advanced ACPI
Configuration settings
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Advanced ACPI Configuration
3.3.3.1 Advanced ACPI Configuration
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
Advanced ACPI Configuration
Enable RSDP pointers to
64-bit Fixed System
Description Tables. Di
ACPI version has some.
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
ACPI Version Features
ACPI APIC support
AMI OEMB table
Headless mode
[ACPI v3.0]
[Enabled]
[Enabled]
[Disabled]
ACPI Version Features
Set this value to allow or prevent the system to be complaint with the ACPI 2.0
specification.
ACPI 3.0 / ACPI 2.0 / ACPI 1.0
ACPI APIC Support
This option allows you to define whether or not to enable APIC features.
