3.3.5.3 Set VLAN Configuration
BIOS Setup Utility
Main
Advanced
PCI/PnP Boot Security Chipset Exit
Setup VLAN ID Configuration
Press Enter and [OK] to save
LAN configure
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Current VLAN ID Status
VLAN Tagging
VLAN ID
Save VLAN ID Configuration
[Enabled]
[Enabled]
[033]
Current VLAN ID Status
Read only. It can not be modified in user mode.
VLAN Tagging
Enable / Disable VLAN Tagging.
Enabled / Disabled
VLAN ID
Enter VLAN ID.
Save VLAN ID Configuration
Press Enter and [OK] to save VLAN configure.
Disabled / Enabled
