3.3.7.1 USB Mass Storage Device Configuration
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security Chipset Exit
USB Mass Storage Device Configuration
Number of seconds
POST waits for the USB
mass storage device
after start unit command
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
USB Mass Storage Reset Delay
Device #1
Emulation Type
Device #2
Emulation Type
[20 Sec]
xxxxxxxxxx
[Auto]
xxxxxxxxxx
[Auto]
USB Mass Storage Reset Delay
Number of seconds POST waits for the USB mass storage device after the start unit
command.
20 Sec / 10 Sec / 30 Sec / 40 Sec
Device #1 / Device #2
Read only. It can not be modified in user mode.
Emulation Type
If Auto, USB devices less than 530 MB will be emulated as Floppy and remaining
as hard drive. Forced FDD option can be used to force a HDD formatted drive to
boot as FDD (Ex. ZIP drive).
Auto / Floppy / Forced FDD / Hard Disk / CDROM
