7
LAN
Port Q'ty
(2)
Controller
Intel 82574L
Storage SATA
Connector
(1) Mini-SAS
Controller
AMD SP5100
Speed
3.0 Gb/s
RAID
RAID 0/1/10/5 (Promise Integrated Software RAID)
Graphic
Connector type
D-Sub 15-pin
Resolution
1600x1200@60Hz
Chipset
Aspeed AST2050
Infiniband
Port Q'ty / Speed
(1) QSFP port / 40Gb/s
Chipset
Mellanox ConnectX IB MT25408A0-FCCR-QIS
Feature
QDR (Quad. Data Rate)
Input /Output
USB
(4) USB 2.0 ports (2 at rear, 2 via cable)
COM
(1) port
VGA
(1) D-Sub 15-pin VGA port
RJ-45
Total (2) GbE ports, (1) shared with IPMI
Power
Proprietary 20-pin (12V single input) power
connector
Front Panel
(1) 2x12-pin SSI front panel header
SATA
(1) Mini-SAS connector for (4) SATA II
System
Monitoring
Chipset
Winbond W83795G
Voltage
Monitors voltage for CPU, memory, chipset & power
supply
Fan
Total (3) 8-pin headers
Temperature
Monitors temperature for CPU & system
environment
LED
Fan fail LED indicator / Over temperature warning
indicator / Fan & PSU fail LED indicator
Others
Chassis intrusion detection / Watchdog timer
support
Server
Management
Onboard Chipset
Onboard Aspeed AST2050
AST2050 IPMI
Feature
IPMI 2.0 compliant baseboard management
controller (BMC) / USB 2.0 virtual hub / BIOS
update
AST2050 iKVM
Feature
24-bit high quality video compression / Dual 10/100
Mb/s MAC interfaces
BIOS
Brand / ROM size
AMI / 4MB
Feature
Plug and Play (PnP) /PCI2.3 /WfM2.0 /SMBIOS2.3
/PXE boot / ACPI 2.0 power management /Power
on mode after power recovery / User-configurable
H/W monitoring
Physical
Dimension
Form Factor
Proprietary
Board Dimension
6.3"x18" (160.02x457.2mm)
Operating System
OS supported list
Please visit our Web site for the latest update.
