3.7.1.1 Memory Configuration
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security
Chipset
Exit
Memory Configuration
Enable Bank Memory
Interleaving
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
Bank Interleaving
Node Interleaving
Channel Interleaving
CS Sparing Enable
Bank Swizzle Mode
[Auto]
[Disabled]
[Auto]
[Disabled]
[Enabled]
Bank Interleaving
Bank Interleave setting has to do with the actual RAM chip properties, most good
quality RAM chips have "4-bank interleaving" and work best at this setting. Inter-
leaving controls how actual hits to memory takes place.
Enable Bank Memory Interleaving.
Auto / Disabled
Node Interleaving
Enable Node Memory Interleaving.
Disabled / Enabled
Channel Interleaving
Enable Channel Memory Interleaving.
Auto / Disabled
CS Sparing Enable
Reserve a spare memory rank in each node.
Disabled / Enabled
Bank Swizzle Mode
Enable or disable bank swizzle mode.
Enabled / Disabled
