3.7.3.2 Hyper Transport Configuration
BIOS Setup Utility
Main Advanced PCI/PnP Boot Security
Chipset
Exit
Hyper Transport Configuration
Enabled: HT supports 52-bit
physical addressing.
Disabled: HT supports 40-bit
physical addressing.
← Select Screen
↑↓ Select Item
Enter Go to Sub Screen
F1 General Help
F10 Save and Exit
ESC Exit
HT Extended Address
HT3 Link Power State
HT Link Tristate
[Disabled]
[Auto]
[Auto]
HT Extended Address
Enabled: HT supports 52-bit physical addressing.
Disabled: HT supports 40-bit physical addressing.
Disabled / Enabled / Auto
HT3 Link Power State
Select the HT3 Link Power State.
Auto / LS0 / LS1 / LS2 / LS3
HT Link Tristate
Select the HT1 Link Tristate mode.
Auto / Disabled / CAD/CTL / CAD/CTL/CLK
