Tiger 230 S2507
5
1.2 Hardware Specifications
Dual ZIF PGA370 Socket
Intel Pentium III, Celeron (only single socket) FC-PGA
Onboard VRM
Front side bus support for 100 or 133MHz
One 2x/4x mode AGP slot
Five 32-bit PCI v2.2 compliant slots
Total six usable slots
VIA Apollo Pro 133A chipset
(VT82C694X and VT82C686B)
Integrated hardware monitoring
3-pin Fan Monitoring headers
2-pin External SCSI LED header
Temperature and Voltage Monitoring
3-pin Wake on Modem header
One floppy connector for up to two drives
Two 9-pin UART serial ports
One 25-pin ECP/EPP parallel port
Four USB ports (two ports via cable - optional*)
PS/2 mouse and keyboard ports
Four 168-pin 3.3V DIMM sockets
Supports up to 2GB @ 100MHz (4 DIMMS)
Supports up to 1.5GB @ 133MHz (3 DIMMS)
Supports PC100/133 SDRAM
Expansion Slots
Chipset Information
Hardware Monitoring
Memory
Integrated I/O
Processor Information
Integrated PCI IDE
Two channel master mode
Supports up to four Enhanced IDE devices
Support for UltraDMA-33/66/100 IDE devices and
ATAPI compliant devices
Award BIOS 2 Mbit Flash
Auto-detection of memory size
Auto-configuration of IDE hard disk types
User settings of hardware monitoring
Multiple boot options
DMI 2.0 compliant
BIOS
* extra accessories can be purchased at the Tyan Online Store: http://www.etyan.com
ATX 2.03 12” x 9.6” (304.8 x 243.84 mm)
One 20-pin ATX power connector
Stacked mouse & keyboard ports
Stacked two USB ports
Two serial ports
FCC Class B (Declaration of Conformity)
European Community CE (Declaration of Conformity)
Taiwan BSMI Notice (Declaration of Conformity)
Form Factor
Regulatory
