TFP1350
GRAPH B
2-1/2 INCH (DN65) MODEL DV-3 DELUGE VALVE
— WET PILOT DESIGN CRITERIA —
SUPPLY PRESSURE,
(5,5)(2,6)
40
(1,4)
20
(4,1)
60 80
(6,9)
100
(8,3)
120
(9,7)
140
(11,0)
160
(12,1)
175
0
EQUIVALENT LENGTH
OF VERTICALAND
HORIZONTAL PIPE
PLUS FITTINGS:
A
B
C-
-
-
300 FT. (90 m)
200 FT. (60 m)
100 FT. (30 m)
D - 400 FT. (120 m)
E - 500 FT. (150 m)
10 (3,05)
20 (6,10)
30 (9,14)
40 (12,19)
50 (15,24)
60 (18,29)
70 (21,34)
80 (24,38)
90 (27,43)
100 (30,48)
MAXIMUM PILOT HEIGHT, FEET (METRES)
NOTE: IF SUPPLY PRESSURE IS VARIABLE,
ASSUME MINIMUM EXPECTED VALUE. PSI
(
BAR
)
A
B
C
D
E
OBSOLETE
