Low Pressure Alarm Switch and drain-
age of the pilot line condensate should
be performed quarterly as follows.
1. Close the Diaphragm ChamberSup-
ply Control Valve.
2. Close the Main Control Valve.
3. Open the Main Drain Valve.
4. Drain the dry pilot line condensate
as follows.
a. Close the Gauge Test Valve lo-
cated below the Dry Pilot Line
Pressure Gauge.
b. Remove the 1/4" Plug from the
Gauge Test Valve.
c. Crack Open the Gauge Test
Valve and allow all conden-
sate, if any, to drain out.
d. Close the Gauge Test Valve,
replace the Plug, and then
open the Gauge Test Valve.
5. Open the Inspector’s Test Connec-
tion, and slowly relieve pneumatic
pressure. Verify that the Low pres-
sure Alarm Switch is operational and
that the low pressure set points are
as follows:
• Low pressure alarm setting at
approximately 6 psi (0,4 bar)
below the minimum pilot line
service pressure requirement
shown in Graph C.
• Fire alarm setting at approxi-
mately 15 psi (1,0 bar) below
the minimum pilot line service
pressure requirement shown
in Graph C.
6. Close the Inspector’s Test Connec-
tion, and allow the Dry Pilot Line to
automatically repressurize.
7. Open the Diaphragm Chamber Sup-
ply Control Valve.
8. Slowly open the Main Control Valve.
Close the Main Drain Valve as soon
as water discharges from the drain
connection. Observe the Automatic
Drain Valve for leaks. If there are
leaks, determine/correct the cause
of the leakage problem. If there are
no leaks, fully open the Main Control
Valve.
WARRANTY
Seller warrants for a period of one year
from the date of shipment (warranty
period) that the products furnished
hereunder will be free from defects in
material and workmanship.
For further details on Warranty, see
Price List.
ORDERING PROCEDURE
All orders for Model F470H Multimatic
Deluge Valves, trim, accessories, and
replacement parts must include the
description and Product Symbol
Number (PSN), where applicable.
Valves:
Unless otherwise specified, the F470H
Valves will be provided with ANSI
flange drilling.
Specify: (specify size) Model F470H
Horizontal Multimatic Deluge Valve
with (specify abbreviation — refer to
Table A, Page 2) flange drilling, PSN
(specify).
ANSI
4" (100 mm) . . . . . . . . . . . . . . PSN 52-471-1-013
6" (150 mm) . . . . . . . . . . . . . . PSN 52-471-1-015
ISO
4" (100 mm) . . . . . . . . . . . . . . PSN 52-471-4-113
6" (150 mm) . . . . . . . . . . . . . . PSN 52-471-4-115
AS
4" (100 mm) . . . . . . . . . . . . . . PSN 52-471-4-313
6" (150 mm) . . . . . . . . . . . . . . PSN 52-471-4-315
JIS
4" (100 mm) . . . . . . . . . . . . . . PSN 52-471-4-713
6" (150 mm) . . . . . . . . . . . . . . PSN 52-471-4-715
“Standard Order” Black Trim:
Specify: Black (specify type trim) for
use with the Model F470H Horizontal
Multimatic Deluge Valve, PSN (spec-
ify).
Wet Pilot Actuation
Trim . . . . . . . . . . . . . . . . . . PSN 52-471-1-201
Dry Pilot Actuation
Trim . . . . . . . . . . . . . . . . . . PSN 52-471-1-202
Electric Actuation
Trim With 24VDC
Solenoid Valve. . . . . . . . . . PSN 52-471-1-203
“Special Order” Galvanized Trim:
Specify:Galvanized (specify type trim)
for use with the Model F470H Horizon-
tal Multimatic Deluge Valve, PSN
(specify).
Wet Pilot Actuation
Trim...................PSN52-471-2-201
Dry Pilot Actuation
Trim...................PSN52-471-2-202
Electric Actuation
Trim With 24VDC
Solenoid Valve . . . . . . . ...PSN52-471-2-203
“Special Order” Electric Actuation
Trim With Separately Ordered Sole-
noid Valve:
Specify: (Specify black or galvanized)
Electric Actuation Trim With Sepa-
rately Ordered Solenoid Valve for use
with the Model F470H Horizontal Mul-
timatic Deluge Valve.
When ordering “Electric ActuationTrim
With Separately Ordered Solenoid
Valve”, refer to Technical Data Sheet
TD119 for information on separately
ordered, UL Listed Solenoid Valves
that may be suitable for use in hazard-
ous locations or that have voltage rat-
ings other than 24VDC.
NOTE
Factory Mutual Approval for electric
actuation of the F470H Valve is con-
tingent on the use of the FMApproved
24VDC Solenoid Valve provided with
the “Standard Order” Electric Actua-
tion Trim, PSN 52-470-1-103 or PSN
52-470-2-103.
Accessories:
Refer to the following Technical Data
Sheets (TD), as applicable.
PressureAlarmSwitch ........ TD213
Low Pressure Alarm Switch. . . . . TD210
Model F324 Air Maintenance
Device ................... TD111
Model F326 Air Maintenance
Device ................... TD112
Model F328 Nitrogen Maintenance
Device ................... TD113
DesiccantDryer.............. TD135
Model F180 or F184
Manual Control Stations. . . . . . TD121
Valve Replacement Parts Kit:
The Valve Replacement Parts Kit con-
tains a Clapper Facing, Diaphragm,
and Handhole Cover Gasket. It is rec-
ommended to have these parts readily
available when servicing the Model
F470H Horizontal Multimatic Deluge
Valve.
Specify: Valve Replacement Parts Kit
for use with (specify size) inch Model
F470H Horizontal Multimatic Deluge
Valve.
4"(100mm) ..............PSN92-470-1-101
6"(150mm) ..............PSN92-470-1-102
-11-
