10.2.3 GENERAL FAULT Sentence Structure
This sentence is identical to the ZONAL FAULT message except for the description field:
Any fault on panel 1 would generate the following sentence:
$FRALA,,FR,OT,01,901,H,B,PANEL 01 GENERAL FAULT*0F<CR><LF>
The HEX data is:
24 46 52 41 4C 41 2C 2C 46 52 2C 4F 54 2C 30 31 2C 39 30 31 2C 48 2C 42 2C 50
41 4E 45 4C 20 30 31 20 47 45 4E 45 52 41 4C 20 46 41 55 4C 54 2A 30 46 0D 0A
All faults cleared on panel 1 would generate the following sentence:
$FRALA,,FR,OT,01,901,N,B,PANEL 01 NO FAULTS*0D<CR><LF>
The HEX data is:
24 46 52 41 4C 41 2C 2C 46 52 2C 4F 54 2C 30 31 2C 39 30 31 2C 4E 2C 42 2C 50
41 4E 45 4C 20 30 31 20 4E 4F 20 46 41 55 4C 54 53 2A 30 44 0D 0A
10.2.4 MAINS FAULT Sentence Structure
This sentence is identical to the ZONAL FAULT message except for the description field:
A mains fault on panel 1 would generate the following sentence:
$FRALA,,FR,OT,01,901,H,B,PANEL 01 MAINS FAULT*01<CR><LF>
The HEX data is:
24 46 52 41 4C 41 2C 2C 46 52 2C 4F 54 2C 30 31 2C 39 30 31 2C 48 2C 42 2C 50
41 4E 45 4C 20 30 31 20 4D 41 49 4E 53 20 46 41 55 4C 54 2A 30 31 0D 0A
Mains fault cleared on panel 1 would generate the following sentence:
$FRALA,,FR,OT,01,901,N,B,PANEL 01 MAINS FAULT CLEAR*7E<CR><LF>
The HEX data is:
24 46 52 41 4C 41 2C 2C 46 52 2C 4F 54 2C 30 31 2C 39 30 31 2C 4E 2C 42 2C 50
41 4E 45 4C 20 30 31 20 4D 41 49 4E 53 20 46 41 55 4C 54 20 43 4C 45 41 52 2A
37 45 0D 0A
10.2.5 BATTERY FAULT Sentence Structure
This sentence is identical to the ZONAL FAULT message except for the description field:
A battery fault on panel 1 would generate the following sentence:
$FRALA,,FR,OT,01,901,H,B,PANEL 01 BATTERY FAULT*14<CR><LF>
The HEX data is:
24 46 52 41 4C 41 2C 2C 46 52 2C 4F 54 2C 30 31 2C 39 30 31 2C 48 2C 42 2C 50
41 4E 45 4C 20 30 31 20 42 41 54 54 45 52 59 20 46 41 55 4C 54 2A 31 34 0D 0A
Battery fault cleared on panel 1 would generate the following sentence:
$FRALA,,FR,OT,01,901,N,B,PANEL 01 BATTERY FAULT CLEAR*6B<CR><LF>
The HEX data is:
24 46 52 41 4C 41 2C 2C 46 52 2C 4F 54 2C 30 31 2C 39 30 31 2C 4E 2C 42 2C 50
41 4E 45 4C 20 30 31 20 42 41 54 54 45 52 59 20 46 41 55 4C 54 20 43 4C 45 41
