Tylo SENSE COMBI ELITE Installation & User Guide

1
L1 L2 GND
208-240V, 1-ph
High Limit Control
Heater
High Limit Control Water tank
Switch
Type
kW
Amp Amp
208 V~ 240 V~
AWG AWG
Sense
Combi-U 7
Sense
Combi-U 8
5.3
6.3
7.0
8.3
26
30
-
-
10
8
-
-
-
-
30
35
-
-
8
8
Use only 194° F copper wire
Don´t forget to earth (ground)!
GND
MH
X1 X2 X3
X4 X5
X6
X7
X8 X9 X10 X11 X12 X13 X14 X15 X16
X17 X18
H3 H2 H1 H.Tank Light Aux 0
Sec/NTC
12345G
BB4140
2
P2
1
P1
3
P3
f e d c b a
6 5 4 3 2 1
FRONT
MIDDLE
BACK
GND GND
GND
WATER TANK
Electrodes
Circuit board
120 V~
AWG 14
Max 6 Amp.
N
120 Volt Light input
(Separate from
Heater Power)
Output to light
13
42
NTC (Sensor) Ext Switch Door Switch Sec/NTC Add On
+($7(5:,5,1*',$*5$0
