E
MAINTENANCE
E
▶ AIR CLEANER CLEANING
<Squeezing dust>
To remove the dust from the evacuator
valve squeeze it between thumb and
fingers to let excess dust out and wipe
around the valve to keep it clean from
outside.
4. Remove the transmission oil cap at
the top of hydraulic cylinder case.
5. Fill the transmission oil to the
correct level on the sight window.
6. After filling, install the cap.
7. Run engine for a few minutes and
stop it.
8. Check the oil level.
Add if required.
▶ REPLACING HST FILTER
1. Remove the HST filter at the front of
the HST unit with filter wrench.
2. Smear lightly the rubber seal on the
new filter with oil to ensure.
3. Tighten the filter until the seal
contacts the base and then turn it
another 2/3 turn to tighten it.
11
HST FILTER
TRANSMISSION OIL CAP
BODY
ELEMENT
DUST VALVE
COVER
