E
MAINTENANCE
E
<Main fuses>
The wiring harness is equipped with
main fuses who’s function is to preserve
the wiring.
However when a main fuse blows the
entire circuit is dead.
Always check the reason & rectify before
replacing the fuse of the same value.
To indicate that the fuse is blown it will
be discolored.
▶ CHECKING AND REPLACING FUSE
<Body fuse box>
Fuses are installed in this tractor to
prevent any possible accident in case of
wiring circuit malfunction.
If the electric system is malfunctioning
during driving, check for any blown fuse.
1. Remove the cover of the fuse box.
2. Remove the blown fuse.
3. Fit a new fuse with the same
c
apacity.
4. The function and capacity of each
fuse are indicated on the cover of
the fuse box.
17
FUSE CASE
NORMAL OPEN CIRCUIT
If using fuses other than the specified,
wirings can be overheated, leading to a
fire.
Never use a fuse with different capacity.
Also, never use a steel wire or foil
instead of a fuse.
WARNING
Always check the reason for a blown
fuse otherwise the new fuse is also likely
to blow.
IMPORTANT
To Next Page
